# Apolo Documentation Chatbot
The **Apolo Documentation Chatbot** enables users to query Apolo’s technical documentation seamlessly, providing quick and accurate answers. Here’s how we built it.
### **Step 1:** Set Up the Apolo RAG Architecture
The first step involves preparing the data infrastructure to support efficient querying and response generation. Here's what we'll do:
1. **Define the data storage structure**: Create a PostgreSQL schema with vector extensions to store embeddings and enable full-text indexing for fast retrieval.
2. **Chunk the documentation**: Preprocess the Apolo documentation into manageable text chunks for embeddings and efficient retrieval.
3. **Generate embeddings**: Use an embedding LLM to convert text chunks into numerical representations for semantic search.
4. **Ingest data into PostgreSQL**: Store the processed chunks and their embeddings in the database for future queries.
Here’s how we implemented this:
```python
def build_apolo_docs_rag():
table_name = "apolo_docs"
chunk_size = 1024
chunk_overlap = 100
print("1. Processing data")
apolo_docs_path = clone_repo_to_tmp(
repo_url="https://github.com/neuro-inc/platform-docs.git"
)
markdown_files = glob.glob(os.path.join(apolo_docs_path, "**/*.md"), recursive=True)
docs = list(
chain.from_iterable(
[UnstructuredMarkdownLoader(f).load() for f in markdown_files]
)
)
chunks = RecursiveCharacterTextSplitter(
chunk_size=chunk_size, chunk_overlap=chunk_overlap
).split_documents(docs)
print("2. Get ebeddings")
sentences = [x.page_content for x in chunks]
embeddings = get_embeddings(sentences=sentences)
print("3. Ingest data")
create_schema(table_name=table_name, dimensions=len(embeddings[0]))
insert_data(
table_name=table_name, embeddings=embeddings, sentences=sentences, batch_size=64
)
```
**Breaking Down the Steps**
* **Processing Data**:\
The `clone_repo_to_tmp()` function pulls the Apolo documentation repository, and the UnstructuredMarkdownLoader processes *`.md`* files into raw text. The text is then chunked into overlapping segments using RecursiveCharacterTextSplitter, which ensures each chunk retains contextual relevance.
* **Generating Embeddings**:\
To represent text chunks numerically, we use the `get_embeddings()` function. It leverages the embedding LLM hosted on Apolo’s platform to create vector representations for semantic search.
```python
def get_embeddings(sentences: List[str], batch_size: int = 4) -> List[List[float]]:
embeddings = []
embedding_client = get_embedding_client()
for i in tqdm(range(0, len(sentences), batch_size)):
sentences_batch = sentences[i : i + batch_size]
response_batch = embedding_client.embeddings.create(
input=sentences_batch, model="tgi"
)
embeddings.extend([x.embedding for x in response_batch.data])
return embeddings
```
* **Ingesting Data**: The processed chunks and embeddings are stored in PostgreSQL. Using vector extensions (pgvector), we create a table with a schema that supports vector-based operations for semantic search.
```python
def create_schema(table_name: str, dimensions: int):
conn = get_db_connection()
conn.execute("CREATE EXTENSION IF NOT EXISTS vector")
conn.execute("CREATE EXTENSION IF NOT EXISTS pg_trgm;")
register_vector(conn)
conn.execute(f"DROP TABLE IF EXISTS {table_name}")
conn.execute(
f"CREATE TABLE {table_name} (id bigserial PRIMARY KEY, content text, embedding vector({dimensions}))"
)
conn.execute(
f"CREATE INDEX ON {table_name} USING GIN (to_tsvector('english', content))"
)
```
### **Step 2: Query the Apolo Documentation**
Once the RAG architecture is set up, the next step is enabling queries. The system retrieves relevant documentation chunks, generates a response using a generative LLM, and logs the interaction for continuous improvement.
Here’s the query flow:
1. **Retrieve relevant chunks**:
* Use **semantic search** to find embeddings closest to the query embedding.
* Use **keyword search** for matching phrases or terms in the text.
2. **Re-rank results**: Combine results from semantic and keyword searches and sort them by relevance using a reranker model.
3. **Generate the response**: Augment the top-ranked chunks with the user query to create a context-rich prompt for the generative LLM.
4. **Log results**: Store the query, context, and response in Argilla for feedback and future fine-tuning.
```python
def query_apolo_docs_rag(query: str = "How to run mlflow?"):
table_name = "apolo_docs"
print("1. Get query embedding.")
query_embedding = get_embeddings(sentences=[query])[0]
print("2. Run semantic search.")
semantic_search_result = semantic_search(
table_name=table_name, query_embedding=query_embedding, top_n=20
)
print("3. Run keyword search.")
keyword_search_result = keyword_search(table_name=table_name, query=query, top_n=20)
print("4. Rerank results.")
search_result = rerank(
query=query, sentences=semantic_search_result + keyword_search_result, top_n=5
)
print("5. Augment & generate.")
context = "\n".join(search_result)
response = generate_with_context(query=query, context=context)
console = Console()
console.print(Panel(response, title="Generated Response", border_style="green", style="bold green"))
print("6. Save response.")
log_sample(
query=query,
context=context,
response=response,
dataset_name=table_name,
keyword_search="\n".join(keyword_search_result),
semantic_search="\n".join(semantic_search_result),
)
```
### **Step 3:** Continuous Improvement with Argilla
Feedback loops are critical for improving RAG applications. Using Argilla:
* Each query, context, and response is logged for evaluation.
* Users can rate the relevance of contexts and responses, enabling targeted fine-tuning of embeddings, search algorithms, or even the LLM itself.
```python
def log_sample(
query: str,
context: str,
response: str,
semantic_search: str,
keyword_search: str,
dataset_name: str,
):
client = rg.Argilla(api_url=ARGILLA_URL, api_key="admin.apikey")
dataset = client.datasets(name=dataset_name)
if not dataset.exists():
settings = rg.Settings(
fields=[
rg.TextField(name="query"),
rg.TextField(name="response"),
rg.TextField(name="context"),
rg.TextField(name="semantic_search"),
rg.TextField(name="keyword_search"),
],
questions=[
rg.RatingQuestion(
name="context_relevance",
title="Relevance of the context",
values=[1, 2, 3, 4, 5],
),
rg.RatingQuestion(
name="response_relevance",
title="Relevance of the response",
values=[1, 2, 3, 4, 5],
),
],
)
dataset = rg.Dataset(
name=dataset_name,
settings=settings,
workspace="admin",
client=client,
)
dataset.create()
record = rg.Record(
fields={
"query": query,
"context": context,
"response": response,
"semantic_search": semantic_search,
"keyword_search": keyword_search,
}
)
dataset.records.log([record])
```
---
